Manual Hand Turbine Lift Gantry Crane
Adjustable height; height can be adjusted to any position under the conditions of technology, and when you adjust the height, it can also lift the heavy load, universal wheels with brake, mobile moving.
Height is adjusted by the turbine for lifting, allowing for flexible adaptation to your needs. The lifting speed can be controlled smoothly, and the crane can be operated manually or electrically, depending on your preference. For outdoor use, you can choose to add a rainproof cover and customize the surface finish with either baking paint or stainless steel.
Infinitely Adjustable Lifting Heights: Featuring a manual hand turbine mechanism, this crane offers the flexibility to adjust lifting heights as needed, supporting variable load capacities.
Specifications
| Item No. | Rated load (ton) |
Total height (mm) |
Lifting height (mm) |
Outside span (mm) |
Inner span (mm) |
H Height (mm) |
| PT2-2 | 1 | 2600-4000 | 3390 | 3000 | 2760 | 410 |
| 1 | 3500-5000 | 4390 | 3000 | 2760 | 410 | |
| 2 | 2600-4000 | 3215 | 3000 | 2690 | 535 | |
| 2 | 3500-5000 | 4215 | 3000 | 2690 | 535 | |
| 3 | 2600-4000 | 3015 | 3000 | 2690 | 685 | |
| 3 | 3500-5000 | 4015 | 3000 | 2690 | 685 | |
| 5 | 2600-4000 | 2910 | 3000 | 2610 | 740 | |
| 5 | 3500-5000 | 3910 | 3000 | 2610 | 740 |
