Foil Base Lamination Machine
JDLM1000/90, 1450/100, 2800/120
JDLM1000/90, JDLM1450/100, JDLM2800/120
Foil Base Lamination Machine
Finished Film Width:
1600-2600 mm
Lamination Thickness:
0.01-0.10 mm
Working Line Speed:
80~250 m/min
Specifications
|
Model |
JDLM1000/90 |
JDLM1450/100 |
JDLM2800/120 |
|
Screw Dia. |
Φ90 mm |
Φ100 mm |
Φ120 mm |
|
Finished film width |
400-900 mm |
700-1300 mm |
1600-2600 mm |
|
Lamination Thickness |
0.01-0.10 mm |
||
|
Main Unwinder Material |
Film. Foil |
||
|
2nd Unwinder Material |
Film. Foil |
||
|
Usable Resin (Coating Grade) |
LDPE, PP, EVA, EAA, Surlyn, Necurel |
||
|
Design Line Speed |
300 m/min |
||
|
Working Line Speed |
80~250 m/min according to material and process art |
||
|
Max. Extrusion Capacity |
150kg/h |
220kg/h |
360kg/h |
|
Main Motor Power |
45 kw |
75 kw |
110 kw |
|
Total power |
160kw |
180kw |
240kw |
|
Dia.of Main Unwinding |
Customize |
||
|
Dia.of 2nd Unwinding |
Customize (Optional) |
||
|
Dia.of Winding |
≤φ1300 mm |
||
|
Power Supply |
380/3/4/50(Volt/Ph/Line/Hz) |
||
Main components
