Tarpaulin Lamination Machine
JDLM2800/120*2, 3400/130*2, 4600/150*2
JDLM2800/120*2, JDLM3400/130*2, JDLM4600/150*2
Tarpaulin Lamination Machine
Finished Film Width:
3400-4400mm
Lamination Thickness:
0.01-0.10 mm
Working Line Speed:
10~120 m/min
Specifications
|
Model |
JDLM2800/120*2 |
JDLM3400/130*2 |
JDLM4600/150*2 |
|
Screw Dia. |
Φ120 mm*2 |
Φ130 mm*2 |
Φ150 mm*2 |
|
Finished film width |
1600-2600mm |
2200-3200mm |
3400-4400mm |
|
Lamination Thickness |
0.01-0.10 mm |
||
|
Main Unwinder Material |
Paper, Fabric |
||
|
2nd Unwinder Material |
Film. Foil |
||
|
Usable Resin (Coating Grade) |
LDPE、PP |
||
|
Design Line Speed |
150 m/min |
||
|
Working Line Speed |
10~120 m/min according to material and process art |
||
|
Max. Extrusion Capacity |
300kg/h Each |
400kg/h Each |
500kg/h Each |
|
Main Motor Power |
75 kw*2 |
90 kw*2 |
110kw*2 |
|
Total power |
340kw |
460kw |
780kw |
|
Dia. of Main Unwinding |
≤φ1200 mm |
||
|
Dia. of 2nd Unwinding |
Customize (Optional) |
||
|
Dia. of Winding |
≤φ1300 mm |
||
|
Power Supply |
380/3/4/50(Volt/Ph/Line/Hz) |
||
Main components
